1.The refill pack and tube do not need to recharge the battery after use.
2.The filling package used in the treatments is pure water. It does not contain harmful or corrosive substances. Care should be taken that it does not suddenly pop out while 3.pressing and removing the cover from the bottom. After filling the water, the caps must be reinstalled.
4.It should not be overcharged, it should only be charged at the appropriate time after being discharged.
5.The negative terminal of the battery that will not be used for a long time should be removed or disconnected.
6.For the connection to be solid; It should be checked regularly that the terminal surface or connection is clean.
8.It should be stored in a dry, well-ventilated place out of direct sunlight at a temperature of between 5 o C and 250 o C. Battery; It should be kept at least 2 m away from heat sources and should be checked and maintained regularly.
10.The screen must be protected from impact by hard materials.
11.The screen should be kept clean and dry.
The status shown on the screen should be checked regularly.
It should be noted whether it gives an audible warning or not.
When the alarm occurs, the battery should be charged immediately.
1.The electrolyte metal in it corrodes cotton products and stone.
2.To avoid electrolyte leakage, the battery should not be reversed.
3.The hydrogen produced during its operation and discharge causes explosion in fire environments.
4.It should be stored and used in well-ventilated environments.
5.There should be no sparks or flames in the environment.
6.When used at temperatures above 45 ° C, the charging current or voltage must be reduced to extend the service life of the battery.
7.The cable should not be pulled when transported with the cable. Otherwise, the cable or terminal will be damaged.
9.Care should be taken not to bump into something during transportation.
BATTERY USE •
Batteries are delivered fully charged. During the storage before installation, the capacity of battery will decrease in different degrees. If the storage time is longer. battery should be recharged.If the storage time is less than 6 months, batteries should be recharged in constant voltage limit current 2.27V/Cell, the maximum current should be less than 0.25C A, charging time 48-72h.
1. Batteries could be in standby use and cycle use. Please charge the battery in constant voltage and limit current, the maximum current : 0.1C10-0.25 C10 A, battery standby use: 25C 2V series: 2.25V/Cell, 6V or 12V series: 2.27V/Cell; battery cycle use: 25C. 2V series: 2.35V/Cell, 6V or 12V series: 2.40V/Cell.
2.If the ambient temperature is too high or too low, in case the ambient temperature exceeds 20C — 30C , then the charging voltage should be adjusted, in case of higher temperature, decreases the charging voltage, and in lower temperature increases the charging voltage, the correction factor : 4mV/C . Besides, that ambient temperature of battery is too high or too low will also influence the capacity and the service life.
•3.Battery should be recharged after the installation or after the discharging, charging the battery in constant voltage limit current mode, charging voltage: 25C 2.35V/Cell, the maximum current: 0.1C10— 0.25C10 A. if discharging in 100% capacity, the charging time is about 24h-27h, if the charging current decreases to a very low current, and retain for 3h almost invariant or the charging electric quantity is 1.15 times of the discharging electric quantity, then consider the battery have been fully charged.
REQUIREMENTS OF BATTERY WORKING MAINTENANCE
1. During the battery working, the operator should take complete working records including battery voltage, current, ambient temperature and other relevant data and working time.
2.Operators should inspect the fastening condition of connecting terminals such as battery overheating or striking fire caused by the connecting strip smudge or loose connecting.
3. Inspecting the total float charging voltage, the operator should use voltmeter to measure the measurement number of battery positive and negative output end voltage is consistent with the indicating float charge voltage, and conforms to the required number of standard float charge voltage under the current temperature.
4. During the battery working, if battery voltage is abnormal, appearance has damage like battery container and cover has flaw or deformation), battery electrolyte leaks, battery temperature is normal, the operator should find the failure
Note
1.There will be no output when it is dissconnected with battery.
2.Please do make sure the positive wire(red) connects the positive terminal and the negative(black) connects the negative.
3.Please read the instructions carefully before use and installation.
4.The voltage of the charger is equivalent with the power grid voltage.Please do not disassemble the equipment unless it is conducted by professional technicaians.
5.The charger should be used in dry and clean environment and avoid moist or dust.
6.0ther parameters unspecified can be customized.
REQUIREMENTS OF INSTALLATION AND USE
♦ Generally, battery are used in series connection, if batteries must be used in parallel connection, then the parallels should not be over two branches. Batteries can work in an ambient temperature of -25.0 —45t. The proper using temperature is 15t —30t. the battery room should have necessary ventilation. ♦ Batteries should be away from source of heat and spark. the security distance should be longer than 1 meter. Batteries should be stored away from direct sunlight. other rays. organic solvent gases and corrosive gases. To improve shockproof capability, the battery rack should be reinforced with foundation bolts. ♦ Batteries are delivered fully charged, so during the transportation and installation, batteries should be prevented from short circuit, be careful of the short circuit caused by batteries and metal parts of battery metal shelf or metal box touches. ♦ When installing the battery wires, the operator should use insulating tools and wear insulating gloves. also remove personal metal articles like watch. bracelets and so on. The operator should screw the bolt tightly during the connection, the proper torque should be 5-7N.M in case of battery overheating or battery striking fire caused by loose connection. ♦Batteries of different models or different capacity cannot be mixed in use. When installing terminal connecting pieces, operators should carefully inspect if the
NOTES FOR BATTERY USE
Don't separate or transform the battery
Don't throw the battery into the water or the fire
SPlease wear insulating gloves when connecting the battery packs
Don't install, use or store batteries in which children can touch
Don't use different brand, different capacity, different voltage and different degree of old and new batteries in series connection
There is acid inside batteries, if battery is damaged by machine and acid splash the
Outdo Battery
The outdo battery, which is in the gel battery family, has a digital display in terms of electronic type batteries. However, this quality battery type, which is designed according to the new VRLA concept, can be easily checked whether it is full during the actual process, unlike other battery types. Outdo batteries, which are in the top quality battery list, are a special battery model with high technologies. In this way, information is sent directly over the system about how often these batteries are active. However, in case of low charge in these professional batteries, this situation is automatically notified to the user directly on the digital screen. At the same time, there are integrated standby mode filling packages at the bottom of the battery cover section.
Outdo Battery Reviews
Outdo batteries, which are one of the best-selling professional batteries in the internet world, have a lot of outdo battery reviews. Looking at the comments made by the users, it can be seen that the professional battery is extremely useful. Many users, on the other hand, state that although the outdo battery has high technology, it has a price that appeals to every budget. It is known that outdo batteries, which are appreciated by their users, have a more effortless use compared to other battery types. Since these batteries automatically communicate with their users in all functions, they offer advantages in terms of both time and cost. In outdo batteries, which are among the most advantageous batteries, when the end period is approached, the filling package can be preferred effortlessly, thus extending the battery service period.
Outdo Battery Origin
Outdo battery origin, which has a very wide usage area, is offered for sale in types such as 65 ah 12 v, 200 ah 12 v. These professional battery models, which are very simple to maintain and apply, are recommended to be mounted directly within 3 months. Outdo batteries, which have a more careful maintenance compared to other battery types, need to be protected from hard and similar damaging factors in the maintenance of the LCD screen. Keeping the screen dry and hygienic and observing the LCD screen on a regular basis are important for the outdo battery to function properly.
Outdo Gel Battery Prices
Outdo gel battery prices, which have a wide variety, have a more attractive price list compared to previous years. However, as with other battery types, the price tariff of these leading battery models varies from company to company. In this respect, in order to reach the most suitable price tariff for outdo batteries, the company site that sells quality and guaranteed outdo batteries, which are experts in their field, should be preferred. Outdo batteries, which have many advantages, are sold over new and second hand, as in other battery models. However, as stated by expert companies, it is recommended to purchase the product on a guaranteed and zero basis in order to obtain high quality and performance in outdo batteries. It is recommended to visit the company website for the price of Outdo batteries.
Outdo Gel Battery Reviews
One of the curious points about outdo batteries, which can be ordered 24/7 in the comfort of home, is outdo gel battery reviews. Outdo gel batteries, which are preferred worldwide, have a different design and operation than other batteries and receive positive comments from their users. Many outdo gel battery users state that they are extremely satisfied with the product. Many users, on the other hand, state that outdo batteries have an easy maintenance and that they provide a signal via the battery digital panel, especially with the decrease of the charge state. In this way, the outdo battery, which is among the advantageous batteries, is also recommended by Turkey users. To purchase outdo batteries, the official outdo battery sales site should be visited.
Outdo Gel Battery Complaint
Since outdo gel batteries sold on the original product guarantee company site have a flawless functioning, outdo gel battery complaint messages are out of question. Outdo gel batteries, which have the best price guarantee, are appreciated by their users because they have maximum energy and move with technology. Outdo gel battery, which is the most prestigious battery of 2019, is also preferred by professional battery companies thanks to its high performance in the field. Outdo gel batteries, which have a cheap price tariff, are variable, but the filling time can exceed 8 years. Outdo gel batteries, which are mostly preferred in wind energy, solar energy and photovoltaic systems, have a wide range of use.
Outdo Gel Battery 200 Amps
Among the outdo gel batteries, which have different models, as in other battery types, outdo gel battery, especially the 200 amp type, is preferred both in our country and around the world. This high-tech mo
AGROMOT BATTERY WARRANTY SPECIFICATION
How long is the warranty period from the date of sale of the battery?
1. Warranty Period for all Agromot AGM Deep Cycle Gel Batteries is 2 years (24 months).
2. The warranty period of the goods replaced under warranty is the remaining warranty period of the first purchased goods. The warranty period is not restarted. Where and how can I have the battery checked during the warranty period?
1. You can get service by sending the product to the factory address written on the invoice, by packing it in a way to be sure of its soundness, provided that the product is invoiced to the nearest cargo or transport company in your region. For support, you can get detailed information and service from the customer support line at www.agromot.com.tr.
2. The relevant transport company or the customer is responsible for the damage of the product sent for warranty during transportation.
What should I do if the battery fails?
In case of malfunction of the accumulator, the relevant dealers should be contacted immediately with the product invoice. In case of any intervention to the battery other than authorized services, the battery is out of warranty.
Does the warranty period change if the battery is replaced under warranty? As a result of the inspection of the defective battery by the authorized service, it will replace the fabricated defective battery with an equivalent new one, which is discovered within the warranty period from the date of sale.
The warranty period of the battery replaced during the warranty application is limited to the remaining warranty period of the first purchased battery.
In which cases are batteries not covered under warranty?
The battery is not covered by the warranty as a result of the situations described below in the analysis of the battery by the authorized service.
a) Errors and malfunctions in the hardware of the system (Charge Regulator, alternator, conductor, leakage in the electrical installation, lamp that remains constantly on, use of instantaneous water heater, overcurrent buffer drawn as a result of the use of resistance, 1.5 times the wattage of the battery capacity in the system and above) inwerter usage, webasto, etc.) plate wear caused by charging after hardening of the battery,
b) Explosions caused by current discharge due to static electricity, short-circuiting of battery terminals and loose connection, battery and system damages caused by not connecting the polarity of the battery in accordance with the system cable polarity (reverse connection),
c) After the battery is installed in the system, wear (deformation, impact, crack, etc.)
d) Premature wear and tear resulting from battery selection that is not suitable for the system is not covered by the warranty.
e) Instant high current devices added to the system later, AC Air Conditioner etc. It should be checked that the hardware is within the capacity of the accumulator defined for the system. Otherwise, the battery is not covered by the warranty.
f) Malfunctions due to storage of the battery in unsuitable conditions (direct sunlight, snow or rain), exposure to extreme heat or cold.
g) In systems operating with two batteries, either in series (24V) or in parallel (12V), in cases where a separate output from any of the batteries causes an imbalance in the charge or discharge of the battery, it is not covered by the warranty.
h)- If the Battery Swells, Overcharge The swelling of the batteries is due to rapid gas release. In general, small Current Capacity is due to rapid charging of batteries at high currents and high temperatures in a short time. The container/box of the battery is curved from the sides and can be easily seen with the eye.
4-Sulphated Battery that has not been charged for a long time and is completely discharged. If the batteries are not charged for a long time, they will self-discharge 3-5% every month. If the batteries are not fully charged and stored for long periods of time when they are not used (that is, if they are left empty), they fall below 8V in a short time. Normally, even if gel batteries go below 8 Volts, they must be brought back to life. Most are reduced to 10% of their Capacity. The battery that goes below 8V is a sulfated battery, and it is definitely not under warranty. A white sulfate layer begins to form on the surface of the positive and negative plates in the accumulator, where sulphation begins. In batteries that have been waiting in this condition for a long time, this layer becomes stable and the battery becomes inoperable. Sulphated plates need to be charged for a long time with low current in order to be operational. Under load, the voltage difference drops rapidly from 10 V. If the plates have been overcharged for a while, the positive plates can easily break even with a little pressure. If the exposure to overcharging is prolonged, the positive grids will oxidize and the plates will become thinner.
BATTERY OUT OF WARRANTY
c) After the battery is installed in the system, wear that may occur in the battery due to impacts caused by external effects (deformation, impact, crack, etc.),
d) Premature wear and tear resulting from battery selection that is not suitable for the system is not covered by the warranty.
e) Instant high current devices added to the system later, AC Air Conditioner etc. It should be checked that the hardware is within the capacity of the accumulator defined for the system. Otherwise, the battery will not be covered by the warranty.
