Lexron 5.5kw Smart MPPT 500V PV  Inverter 5500wat Off-Grid 48Volt

Lexron 5.5kw Smart MPPT 500V PV Inverter 5500wat Off-Grid 48Volt

Brand:Lexron
Product Code: Ata-HV-5.5KW MPPT
Reward Points: 453
SKU : Lexron 5.5kw MPPT 500V
Product available in stock : 19
  • 17,277.00₺

  • Ex Tax: 14,397.50₺
  • Price in reward points: 45300
  • 10 or more 17,160.00₺
  • 100 or more 17,043.00₺

Available Options


The products can be delivered from the factory, Ankara or Istanbul branch. If you are close to the branches of our company, you can check the stock in our unit close to you by contacting us by phone or e-mail.
Shippment Fee :You can order or order shipping cost. Those who cannot get cheap money from our company.
Dimension 500km 750km1000km+++
Box-Shippment1day2 day 3 day5 day
By Truck3 day 4 day 5 day
7 day
  • Easy to buy & return
  • 100% Secure Payments
  • 24x7 Support Available
  • Shop with our Application

Tags: 5.5kw, 5500watt

Taksit Tutarı
Toplam Tutar
2 x 4.868,40 TL
9.736,79 TL
3 x 3.320,20 TL
9.960,60 TL
4 x 2.548,45 TL
10.193,79 TL
5 x 2.089,31 TL
10.446,56 TL
6 x 1.782,85 TL
10.697,07 TL
Taksit Tutarı
Toplam Tutar
2 x 4.873,61 TL
9.747,22 TL
3 x 3.325,29 TL
9.975,88 TL
4 x 2.554,17 TL
10.216,68 TL
5 x 2.095,08 TL
10.475,42 TL
6 x 1.789,16 TL
10.734,93 TL
Taksit Tutarı
Toplam Tutar
2 x 4.870,48 TL
9.740,95 TL
3 x 3.328,58 TL
9.985,73 TL
4 x 2.558,19 TL
10.232,77 TL
5 x 2.098,95 TL
10.494,75 TL
6 x 1.794,02 TL
10.764,14 TL
Taksit Tutarı
Toplam Tutar
2 x 4.865,27 TL
9.730,54 TL
3 x 3.318,02 TL
9.954,06 TL
4 x 2.546,74 TL
10.186,95 TL
5 x 2.087,87 TL
10.439,37 TL
6 x 1.781,59 TL
10.689,53 TL
Taksit Tutarı
Toplam Tutar
2 x 4.924,24 TL
9.848,48 TL
3 x 3.382,02 TL
10.146,06 TL
4 x 2.617,05 TL
10.468,19 TL
5 x 2.159,72 TL
10.798,62 TL
6 x 1.863,91 TL
11.183,48 TL
Taksit Tutarı
Toplam Tutar
2 x 4.903,55 TL
9.807,09 TL
3 x 3.345,47 TL
10.036,40 TL
4 x 2.568,01 TL
10.272,04 TL
5 x 2.103,56 TL
10.517,80 TL
6 x 1.794,66 TL
10.767,96 TL
Taksit Tutarı
Toplam Tutar
2 x 4.922,11 TL
9.844,22 TL
3 x 3.366,26 TL
10.098,77 TL
4 x 2.592,30 TL
10.369,19 TL
5 x 2.135,90 TL
10.679,50 TL
6 x 1.827,53 TL
10.965,18 TL
Taksit Tutarı
Toplam Tutar
2 x 4.862,15 TL
9.724,30 TL
3 x 3.316,57 TL
9.949,70 TL
4 x 2.547,02 TL
10.188,09 TL
5 x 2.088,35 TL
10.441,77 TL
6 x 1.782,85 TL
10.697,07 TL
Taksit Tutarı
Toplam Tutar
2 x 4.877,79 TL
9.755,57 TL
3 x 3.331,14 TL
9.993,41 TL
4 x 2.560,50 TL
10.241,98 TL
5 x 2.098,22 TL
10.491,12 TL
6 x 1.791,90 TL
10.751,42 TL

Prior to installing modules please obtain information about any requirements and necessary approvals for the site, installation and inspection from the relevant authorities.

Maximum Panel Connection Type, Number of Module

280W Solar Panel Minimum 3 Series, Maximum 14 Series, Maximum 26 Panels

340W Solar Panel Minimum 2 Series, Maximum 12 Series, Maximum 20 Panels

400W Solar Panel Minimum 2 Series, Maximum 9 Series, Maximum 18 Panels

455Wat Solar Panel Minimum 2 Series, Maximum 9 Series, Maximum 16 Panels

· Check applicable building codes to ensure that the construction or structure (roof, facade, support, etc.) can bear the module system load.

· CS-series solar modules have been qualified for Application Class A (equivalent to Safety Class II requirements). Modules rated under this class should be used in systems operating at voltage above 50 V or power above 240 W, where general contact access is anticipated.

· Atakale Solar Inc. modules have been certified  as Type 1 or Type 4 according to UL 1703 andClass C according to IEC 61730-2, please refer to the datasheet or the product nameplate for the detailed types.

· Consult your local authority for guidelines and requirements for building or structural fire safety

When installing modules, ensure the supporting roof has a fire resistant roof covering rated for the application. · The fire rating for this module is only valid when the product is installed as specified in the mechanical mounting instructio

The module is intended for use in general open-air climates, as defined in IEC 60721-2-1: Classification of environmental conditions Part-2-1: Environmental conditions appearing in nature - Temperature and humidity.

· Please consult the atakale Solar Inc. technical  support department for more information on the  use of modules in special climates, , such as an altitude greater than 2000 m.

Exposing modules to salt (i.e. marine environments) or sulfur (i.e. sulfur sources, volcanoes) incurs the risk of module corrosion. · Do not expose modules and their connectors to any unauthorized chemical substances (e.g. oil, lubricant, pesticide, etc.), as modules may incur damages.

· Failure to comply with these instructions will void atakale Solar Inc. limited warranty

Lexron 5.5kw 500V DC Smart Solar inverter  48V DC
Features

Benefits
Built in Wi-Fi for mobile Android/iOS/App
Confgurable AC/PV output usage timer
Supports USB on-the-Go Function,RS232
Selectable hgh power charging current

BMS Communication port RS485-CAN-BUS


Selectable nputvoltage range for App.
Independent battery system design
•Parallel operaton wth 6 units for 7.2

Power Out
PV DC Range
MPPT Charge Current
3,6kw-7,2kw
120V-450V
30A-120A
GTIP Custom Code :85044010 Manufacturer  AXPERT Voltronic
4th Generation Smart Solar Inverter
Conversol Max is the 4th generation off-grid inverter with rich new functions. Its detachable LCD control module can be turned to a remote panel. It’s also integrated with a Bluetooth interface ready for mobile monitoring and supports USB on-the-go function to facilitate data upload/download. Battery independence design enhances this inverter to operate without a battery. You can install a 48V battery bank later on.
The most powerful single-phase inverter with twin turbo-charger that is powered from two solar arrays totaling 8kW. The MPPT charger tracks with great accuracy the maximum power point of your solar panels. Wi-Fi is integrated with the inverter
New Generation Smart Inverter Features
Customizable status LED bar with RGB lights
• Built-in wifi for mobile monitoring (Android/iOS Apps are available)
• Supports USB On-the-Go function
• Reserved communication port for BMS (RS485, CAN-BUS or RS232)
• Replaceable fan design for ease of maintenance
• Battery independent design
• Configurable AC/PV output usage timer and prioritization
• Selectable high power charging current
• Selectable input voltage range for home appliances and personal computers
• Compatible to Utility Mains or generator input
• Built-in anti-dust kit
• Optional DC output for DC fan, LED bulb, router and so on
• Parallel operation up to 6 units only available for 7.2kVA

Wi-Fi Connection
This unit is equipped with a Wi-Fi transmitter. Wi-Fi transmitter can enable wireless communication between off-grid inverters and monitoring platform. Users can access and control the monitored inverter with
downloaded APP. You may find “WatchPower” app from the Apple® Store or “WatchPower Wi-Fi” in Google® Play Store. All data loggers and parameters are saved in iCloud. For quick installation and operation.
Wi-Fi module can enable wireless communication between off-grid inverters and monitoring platform. Users have complete and remote monitoring and controlling experience for inverters when combining Wi-Fi module with WatchPower APP, available for both iOS and Android based device. All data loggers and parameters are saved in iCloud.

Serial Connection and Dry Contact Signal
Please use the supplied serial cable to connect between the inverter and your PC. Install the monitoring software from the bundled CD and follow the on-screen instructions to complete your installation. For detailed
software operation, refer to the software user manual on the bundled CD. There is one dry contact (3A/250VAC) available on the rear panel. It could be used to deliver signal to external device when battery voltage reaches warning level.

BMS Communication
It is recommended to purchase a special communication cable if you are connecting to Lithium-Ion battery banks. Please refer to Appendix II- BMS Communication Installation for details.

Battery Equalization
Equalization function is added into charge controller. It reverses the buildup of negative chemical effects like stratification, a condition where acid concentration is greater at the bottom of the battery than at the top.
Equalization also helps to remove sulfate crystals that might have built up on the plates. If left unchecked, this condition, called sulfation, will reduce the overall capacity of the battery. Therefore, it’s recommended to
equalize battery periodically. In Equalize stage, the controller will supply power to charge battery as much as possible until battery voltage raises to battery equalization voltage. Then, constant-voltage regulation is applied to maintain battery voltage at the battery equalization voltage. The battery will remain in the Equalize stage until setting battery equalized time is arrived

Parallel Function
This inverter can be used in parallel with three different operation modes.
-Parallel operation in single phase is with up to 6 units. The supported maximum output power for 7.2KW model is 43.2KW/43.2KVA. The supported maximum output power for 6.5KW model is 39KW/39KVA.
- Maximum six units work together to support three-phase equipment. Maximum four units support one phase.
- Maximum six units work together to support split-phase equipment only available for 6.5KW model. 5 units support one phase maximum. The supported maximum output power is 39KW/39KVA and one phase can
be up to 32.5KW/32.5KVA.

Pylontech LifePo4 Battery Communication
After configuration, please install LCD panel with inverter and Lithium battery with the following steps. Step 1. Use custom-made RJ45 cable to connect inverter and Lithium battery.
